十字激光模组 515nm 30mW 绿色 线宽度可调 7m线长 24小时连续工作
Cross Laser Module 515nm 30mW Green Line Width Adjustable 7m Length 24 hours Operating
[Feature]
1. Line width adjustable from 0.4 mm to several centimeters.
2. Cross lens angle is selectable from 5° to 120°.
3. The 515nm laser is pure color. The light is clear and bright and soft and not glare.
4. Brand new original imported die, high quality lens, can be opened 24 hours a day.
5. Intelligent driver board with imported ICs 2.8-5.2V wide range power supply.
6. The interior is filled with heat-dissipating silicone and AB glue, which can fully dissipate heat and prevent shock and fall.
7. High temperature resistance, corrosion resistance.
[Specification]
Product Name: 515nm Laser Module
Wavelength: 515nm
Output Power: 30mW
Laser Shape: crosshair
Operating Voltage: DC 2.8-5.2V
Operating Current: ≤180mA
Size: 14*65 mm
Operating Temperature: -10 ~ +50℃
Storage Temperature: -40 ~ +85℃
Include: Laser module + power supply + laser holder
Corsshair Length(Indoors): 7m
Corsshair Length (Non-sun direct in the semi-outdoor): 3m
