974nm 976nm 980nm 300mW~600mW 单模光纤激光 小型模块类型
974nm 976nm 980nm 300mW~600mW SM fiber laser Compact Module type
The 980nm single-wavelength laser uses a high-performance butterfly semiconductor laser chip,
combined with fiber-optic FBG frequency lock to ensure stable spectral wavelength.
The professionally designed drive circuit and TEC control ensure laser safe and stable operation,
single mode or polarization-maintaining pigtail output.
This laser can be used in scientific research and production testing.
It is suitable as a pump laser source for fiber lasers or fiber amplifiers.
[Characteristic]
1. High output power
2. Power and spectrum stability
3. Module or desktop package
[Application]
1. Optical fiber laser pumping
2. Fiber amplifier
3. Nonlinear optics research
[Specifications]


			|
			 Parameter
			 |

			 Unit
			 |

			 Typical value
			 |

			 Remarks
			 |






			|
			 Working wavelength
			 |

			 nm
			 |

			 974±1;976±1
			 |

			 choose
			 |


			|
			 Output power
			 |

			 mW
			 |

			 300mW/400mW/500mW/600mW
			 |

			 Choose
			 |


			|
			 Short term stability(15 Minutes)
			 |

			 dB
			 |

			  ≤ 0.02
			 |


			 |


			|
			 Long-term stability(8 Hours)
			 |

			 dB
			 |

			  ≤ 0.05
			 |


			 |


			|
			 Fiber type
			 |

			 -
			 |

			  PM980 or HI-1060

			 |


			 |


			|
			 Fiber Interface
			 |

			 -
			 |

			  FC/APC
			 |


			               Customizable:
			                1=FC/APC
					2=FC/UPC
					3=SC/APC
					4=SC/PC
					5=FC/PC

			 |



			|
			 Fiber length
			 |

			 M
			 |

			  1m(Default)
			 |


			 |


			|
			 Working temperature
			 |

			 °C
			 |

			  -20 ~ +65
			 |


			 |


			|
			 Storage temperature
			 |

			 °C
			 |

			  -40 ~ +85
			 |


			 |


			|
			 Power supply
			 |

			 -
			 |

			 DC 5V
			 |

			 Power supply Include
			 |


			|
			 Module type size
			 |

			 mm
			 |


			Module A: 90x70x15
			Module B: 150x125x20(Default)
			Module C: 150x125x30

			 |


			We send it randomly.
                         Please contact us if you have size requirements.

			 |
