730nm 1200mW 光纤耦合激光器 实验室半导体激光器 CW模式和调制模式

730nm 1200mW 光纤耦合激光器 实验室半导体激光器 CW模式和调制模式

730nm 1200mW Fiber Coupled Laser Lab Semiconductor Laser CW and Modulation

This product is for multimode fiber coupling of semiconductor laser,the stability of the output power of the fiber is good and the spot pattern can be improved to a great extent.The collimated beam can meet the high requirement of the beam.
Our company produces single wavelength, polarization maintaining and multimode fiber coupled lasers at various wavelengths, as well as fiber optic coupled lasers with fiber coupled lasers.Please contact us.

Notes:
This is a custom product. If you need other output powe or have special requirements, please contact us.
Lead Time: 7~15 workingdays! Custom product available!

[Features]
1.High power stability(<3%)
2.Multimode fiber coupled,fiber output.

[Specifications]
Wavelength:730nm
Output Power:1-1200mW
Operating Temperature: 0°C-40°C
Storage Temperature:  -40°C-85°C


Parameter Work condition Symbol Min. Typical Value Max. Unit
Output Power @PO PO     1200 mW
Power Stability 2hrs Ps     3 %
Central Wavelength @PO λc   730   nm
Spectral linewidth @PO FWHM   2   nm
Fiber core diameter   200um/NA=0.22(Customized)
Fiber Length       100   cm
Fiber Type MM Fiber
Fiber interface     FC/ST/SMA905
Warming Time @PO Tw     5 min
Noise RMS(10Hz-100MHz) N   1   %
Service Life @PO MTBF 10000     Hrs





730nm Fiber Coupled Laser

730nm Fiber Coupled Laser

730nm Fiber Coupled Laser

730nm Fiber Coupled Laser

730nm Fiber Coupled Laser
