532nm 300mW 0.1nm 窄线宽拉曼激光器 绿色拉曼光谱系统

532nm 300mW 0.1nm 窄线宽拉曼激光器 绿色拉曼光谱系统

532nm 300mW 0.1nm Narrow Linewidth Raman Laser Green Raman Spectroscopy System

[Features]
1. Spectral linewidth <0.1nm
2. High power stability: <3%

[Application]
2. Raman spectroscopy
2. Sensing

[Specification]
Product Name: Narrow linewidth raman laser
Wavelength: 532nm
Output Power: 1~300mW (Adjustable)
Operating Temperature: 0°C~45°C
Storage Temperature:  -40°C~85°C

Parameter Work condition Symbol Min. Typical Value Max. Unit
Output Power APC mode PO     300 mW
Spot Mode       TM00
Beam Diameter Po , 1/e2     2.0   mm
Beam Divergence Angle Po , 1/e2     0.5   mrad
Spot Roundness     90     %
Power Stability 2hrs Ps   3 5 %
Spectral Linewidth FWHM PO     <0.1 nm
Spectral Stability λs PO     <0.1 nm
Central Wavelength @PO λc 531.5 532 532.5 nm
Service Life @PO MTBF 5000     Hrs



532nm narrow linewidth raman laser

532nm narrow linewidth raman laser

532nm narrow linewidth raman laser

532nm narrow linewidth raman laser

532nm narrow linewidth raman laser
