532nm 100mW 200mW 300mW 高功率 绿光 激光模组 点状/一字线 定位器/工业定位





532nm 100mW 200mW 300mW 高功率 绿光 激光模组 点状/一字线 定位器/工业定位
532nm 100mw 200mW 300mw High power Green laser module Dot/Line  Locator/Industrial positioning
High power and stable performance lasers.
For green laser pointer, laser flashlight, laser positioning, range finder, medical equipment, electronic production enthusiasts!
Currently, for line laser shape, the highest output power is 200mw, 300mw is out of stock.
Name: 532nm 100mw~300mW High power Green laser module Dot/Line
Output Wavelength: 532nm
Output Power: 100mw/200mw/300mw
Laser Shape: Dot/Line (choice)
Laser type: Visible laser, Green color
Outside Color: Black
Warm-up time: < 1 second
Specifications: continuous output, the expected lifetime is more  than 5000 hours
Size: Φ25x 67mm/ Φ40x 89mm
Exit Pupil Diameter: > Φ0.8mm
Optical Systems: Optical Coated Glass
Operating Voltage: DC 3V
Operating Current: <1A
Laser Class: IIIB
Operating Temperature: 20℃~30℃
Storage Temperature: -10℃~60℃
Beam Divergence: 1mrad
Wiring: Red line is (+), the black line is (-)
Package includes:
1* Green laser module
Warning :
1. All of laser products are harmful for eyes,please don't aim people eyes(contain animal eyes) directly.
2. It is Industrial laser ,not toy .Keep far from Children under 18years old.


green laser line
