TTL调制 850nm 3mW~5mW IR 点红外激光模组

High-quality laser diode, optical glass lens, driver circuit and housing

High reliability, high stability, long life, low price

Industrial marking devices, laser medical equipment, stage lighting and laser targeting devices and so on.

Name: TTL modulation 850nm 3mw~5mw IR Infrared dot laser module

Output Wavelength: 850nm

Output Power: 3mW~5mw(The output can be customized)

Laser Shape: Rectangle

Laser type: Invisible laser, IR laser

Outside Color: Black

Beam Divergence: 0.1mrad ~ 0.6mrad adjustable

Spot Description: Adjustable

Modulation: TTL modulation

Modulation frequency: 1Hz-1000KHz

Operating Voltage: DC 3V ~ 5V

Laser Class: IIIa

Operating Temperature: -10℃~50℃

Storage Temperature: -30℃~80℃

Size: Φ12mm x30mm, Φ16mm x60mm

MTTF: 10000 hours

Warranty: 1 Year Factory warranty

1 The red and yellow lines shorted, the module will be lit, in a continuous mode of operation;

2 To modulate the signal line negative black wire, positive connected to the yellow line, red line vacant, modulation module in working condition.

3 Signal input modulation frequency must be within the range 500KHZ;

1* TTL IR laser module
