473nm 10mw~600mw 蓝色光纤激光器带电源支持定制
473nm 10mw~600mw blue fiber laser with power supply customize fiber diameter & length
Fiber-coupled laser features:
1. The length of fiber can be customized.
2. You can change the direction of the laser beam, it can be applied to a variety of occasions venue.
3. Laser spot is circular, uniform illumination.
4. The laser fiber can be installed at the exit of the collimator lens care area to adjust the size, large or small.
Note:
1. It's made-to-order products, we need 3~10 working days to produce it.
2. The output power/fiber diameter/fiber length can be customized.
3. The marked output power is before coupling, coupling efficiency is about 80%~90%.
[Specifications]
Product Name: 473nm fiber coupled laser with Power Supply
Product Include: Laser system with fiber + Controller + Power source
Output Wavelength: 473nm
Output Power: 10mw~600mw (Choose)
Fiber diameter: 4100um/200um/400um/600um/800um/1000um (Choose)
Fiber length: 1m(default)--(Max 20m,can be customized)
Interface type: FC/PC (default) -- FC/APC, SMA905 (Choose)
Modulation: 0~30khz Analog or TTL
Spatial mode: near TEM01
Operating mode: CW or Modulation
Power Stability: <±5% per 2 hrs
Temperature Stabilizing: TEC
Warm Up Time: <5 minutes
Beam Quality (M2): <2
Optimum Operating Temperature: 20~30℃
Storage Temperature: 10~50℃
MTTF(mean time to failure): 10,000 hrs
Lead Time: 3~10 workingdays! Custom product available
Laser head dimensions: 155(L)x77(W)x60(H) mm
Power Supply #1: Standard type power supply 100(L)x70(W)x55(H)mm
Power Supply #2: Lab Adjustable power supply 178(L)x197(W)x84(H)mm
Warranty: 1 Year
[APPLICATIONS]
Thermal printing
Material Inspection
Scanning Biochemistry
Lidar
[Package include]
1 x 473nm fiber laser
1 x Laser power supply
Fiber coupled laser 473nm 100mw blue laser
