激光和光纤耦合和输出准直器用于445nm 473nm 520nm 671nm 780nm 980nm光纤激光耦合
Laser and fiber coupling and output collimator For 445nm 473nm 520nm 671nm 780nm 980nm fiber laser coupling
Characteristics of fiber laser coupling laser:
1 fiber length can be customized according to customer requirements, easy to move.
2 can change the direction of the light path, can be applied to a variety of occasions.
3 circular light spot, uniform illumination.
4 fiber optic outlet can be installed with a collimator to adjust the size of light area, can be big or small.
Interface type: FC/PC (default), FC/APC, SMA905 (If you need FC/APC or SMA905 interface please leave a comment when you place the order.)
Note:
The output power of the laser fiber-coupled is marked before the power coupling, the coupling efficiency is generally 80%.
e.g. a 3W fiber-coupled laser,the real output power is 2.4W.
The divergence degree of optical fiber light extremely high, our company provide the collimator collimation, collimator size: focal distance less than 30mm, size 23x40mm; focal distance 60mm, the size will be 23x60mm.
All kinds of wavelength and output power laser can be fiber coupled, please contact us if you have any question (sales@naku-tech.com).
