1053nm DPSS激光器 100mW~500mW输出功率可调





1053nm DPSS激光器 100mW~500mW输出功率可调
1053nm dpss laser 100mw~500mw output power adjustable
Wavelength: 1053nm
Output Power: 100mw/200mw/500mw(choose)
Working Mode: CW
Transverse: TEM00
Sepctral Linewidth: <0.1nm
Polarization: Line polarization
Polarizatino Ratio: >8:1
Beam Quality(M2 factor): <1.5
Beam Divergence(full angle,mrad): 1.5±0.2
Beam diameter at Dperture: 2.5±0.2mm
Beam Roundness: >90%
Power stability(RMS): <5%@4hours
Aperture Position: 50mm
Dimensions of Laser Head: 205mm L x 60mm W + 60mm H
Integrated Driver Model Dimensions: 159mm + 144mm + 83mm
External Modulation: 5V TTL / 5V Analogue
Modulation Repetition: 30KHz TTL / 10KHz Analoggue
Cooling System: TEC
Warm-up Time: <15 minutes
Operation Temperature: 18℃ ~ 30℃
Expected Lifetime: > 10,000 hours
Warranty Time: 1 Year

This size is for reference only. The size of the latest model may changed.
If there is any requirement for size, please contact us get latest size.
