655nm 250mW 红色激光模组 宽电压 5V 12V 24V 高功率密室逃逸激光室





655nm 250mW 红色激光模组 宽电压 5V 12V 24V 高功率密室逃逸激光室
655nm 250mw Red laser module Wide voltage 5V 12V 24V High power chamber of Secrets escape laser
Name: 5~24V 250mW High power red laser module continously work laser Factory direct sales
Wavelength: 655nm/±5nm
Output Power: <250mw
Size: Φ20x60mm
Material: Copper + aluminum
Surface Treatment/Color: Black (black oxide)
Service Life: continuous output, continuously working time>6000 hours
Laser Range: 500m~10000m
Laser shape/dimension: Ellipse, < Φ15mm at 10m distance(Focus adjustable)
Circuit Control: ACC line
Work Voltage:DC=5.0~24V
Operating current: I<360mA
Work Temperature: -10 °C~+50°C
Storage Temperature: -40°C~+80°C
Security level: CLASS III B
Package List:
1* laser module(The laser mount and power supply can be choose)
Use of red light modules:
1, can be used for positioning by sight;
2, can be used for laser testing tools;
3, can be used for concentric positioning;
4, can be used for medical equipment positioning;
5, can be used for the production of signal equipment;
Wide voltage Red laser module

Wide voltage Red laser module
