450nm 5mW-50mW 蓝光激光模组 点状/激光定位仪/DC 6V/ TTL模组/ Φ16mm*60mm
450nm 5mW-50mW Blue Laser module Dot /Laser Locator/DC 6V/ Φ16mm*60mm
Such products can be widely used in all kinds of electric tools, the level of scale, locator, range finder, swinger, laser marking instrument and other tools. Can provide a solution for the customers, designed to meet customer demand for laser module.
Specifications:
Output wavelength: 450nm
Output power: 5mw-50mW (choice)
Beam Divergence: 0.1mrad ~ 0.6mrad
Optical Systems: Optical Coated Glass
Spot Description: > Φ0.3mm (Adjustable)
Surface treatment: anodized Black
Shell material: Aluminum
The circuit control: ACC line
Reverse connection protection: Yes
Working voltage: DC 3V/5V/6V
Working current: I<120mA
Threshold Current: 40mA
Preheating time: no
Working temperature: - 10 ℃ ~ 40 ℃
Storage temperature: +10 ℃ ~ 40 ℃
Dimension: Φ16mm*60mm
Structure characteristics: laser tube + lens + radiating shell
Wiring: Red line is (+), the black line is (-)
Continuous working time: > 12 hours(Good heat dissipation)
Warranty: 12 Months
Package includes:
1 x Blue Laser Module Dot
