635nm/637nm/638nm 100mW~150mW 光纤耦合激光器带电源

635nm/637nm/ 638nm 100mw~150mw Fiber coupled laser with power supply

[Specifications
Product Name: 635nm/637nm/ 638nm 100mw~150mw Fiber coupled laser
Lead Time: 7~15 workingdays! Custom product available!
Output Wavelength: 635nm/637nm/ 638nm (+/-5) nm
Output Power: 100mw, 150mw (Choose)
Optical fiber core diameter: 200um(Default) -- (50um/100um/200um/400um/600um/800um/1000um -- Can be customized)
Spatial mode: TEM00
Operating mode: CW or Modulation
Fiber diameter: 100um 200um
Power stability: <3% per 4 hrs
Temperature Stabilizing: TEC
Warm Up Time: <1 minutes
MTTF(mean time to failure): 10,000 hrs
Power Supply: Standard type power supply / Lab Adjustable power supply (Choose)
Modulation:  0~30khz Analog or TTL
Interface type: FC/PC (default), FC/APC, SMA905 (Choose)

[Package include]
1 x 635nm/638nm Fiber coupled  Laser
1 x Laser power supply

Note: The marked output power is before coupling, coupling efficiency is about 80%~90%.


Output power adjustable:
