445/450/455nm 500mWw~4000mW 蓝色光纤耦合激光器 可定制

 445/450/455nm 500mw~4000mw Blue Fiber coupled laser Support customized

[Specifications]

Product Name: 445/450/455nm 500mw~4000mw Blue Fiber coupled laser Support customized

Lead Time: 7~15 workingdays! Custom product available!

Output Wavelength: 450(+/-5) nm

Output Power: 500mw, 1000mw, 1500mw, 2000mw, 3000mw, 4000mw(Choose)

Spatial mode: TEM00

Operating mode: CW or Modulation

Fiber diameter: 100um 200um

Power stability: <3% per 4 hrs

Temperature Stabilizing: TEC

Warm Up Time: <1 minutes

MTTF(mean time to failure): 10,000 hrs

Laser dimensions: 100(L)x40(W)x50(H) mm /114(L)x44(W)x65(H)mm3

Power Supply: Standard type power supply / Lab Adjustable power supply (Choose)

Modulation:  0~30khz Analog or TTL

Interface type: FC/PC (default), FC/APC, SMA905 (If you need FC/APC or SMA905 interface please leave a comment when you place the order.)

[Package include]

1 x 445/450/455nm Fiber coupled  Laser

1 x Laser power supply

Note: The marked output power is before coupling, coupling efficiency is about 80%~90%. For example, the 3W laser's actual output power of fiber coupled laser is >2.4W.
