多点激光模组 焦点可调 99点/线 激光模组
Multi Dot Laser Module Focus Adjustable 99 Points Line Laser Module
[Features]
1. Ultra high brightness, universal in indoor and outdoor.
2. The light is clear and bright, soft and not dazzling.
3. Spot size is adjustable.
4. The shell is made of aviation aluminum-plated insulating paint that can not only fully dissipate heat but also resist shock, drop, and static electricity.
5. Imported laser diodes emit light directly with exceptional stability.
6. Intelligent driver board with imported IC, 2.8-5.2V ultra wide range power supply.
7. High temperature resistance, corrosion resistance
8. Wavelength, power, wire length, working distance, spot effect, etc. can be customized.
[Specifications]
Product Name: Multi Dot Laser Module
Wavelength: 650nm/520nm/450nm (Optional)
Core Power: 100mW
Operating Voltage: DC 2.8V ~ 5.2V
Operating Current: <500mA
Size: 16*70mm
Optical Lens: Grating (imported from Germany)
Installation Height: 0m - 10m can be used
Lens Angle: 19.1°
Line length at 50cm: 16.85cm
Line length at 100cm: 33.7cm
Line length at 150cm: 50.55cm
[Package Include]
1* Laser module
1* Bracket
1* 1~3V Adjustable Power supply
