638nm 100mW 红色 光纤耦合激光器 尾纤激光 带电源

价格:$1.00

(最新的价格,请联系我们.)

请选择:







购买数量:


638nm 100mW 红色 光纤耦合激光器 尾纤激光 带电源

638nm 100mW Red Fiber Coupled Laser Pigtailed Laser With Power Supply

[Specifications]
Product Name: 638nm pigtailed laser
Wavelength: 638±10nm
Output Power: <100mW
Output Mode: Multimode
Multimode Coupling Ratio: >90%
Spot Form: Astigmatism
Fiber Core Diameter: 200μm
Fiber Length: 1m (Customizeable)
Fiber Interface Type: FC/SMA905/LC/SC (Choose)
Fiber Material: Quartz
Coupling Lens Material: Optical glass
Operating Voltage: DC 2.4V
Operating Voltage With Power Diver: DC 3-5V
Operating Current: <200mA
Circuit Control Mode: ACC / TTL frequency modulation (Choose)
Operating Temperature: -10~60℃
Storage Temperature: -40~85℃
Size: Φ20*70mm


NOTE: We can make single mode fiber coupled laser for 638nm,  the maximum output power is about 15MW. Leave a comment if you need single mode fiber coupled laser module.

638nm pigtailed laser

638nm pigtailed laser

638nm pigtailed laser

638nm pigtailed laser

638nm pigtailed laser

638nm pigtailed laser

638nm pigtailed laser

638nm pigtailed laser

638nm pigtailed laser
