980nm 1000mW 红外激光束 高功率光纤耦合激光模组 带电源

980nm 1000mW IR Laser Beam High Power Fiber Coupled Laser Module With Power Supply

[Specifications]
Product Name: 980nm pigtailed laser
Wavelength: 980±5nm
Output Power: <1000mW
Output Mode: Multimode
Multimode Coupling Ratio: >90%
Spot Form: Astigmatism
Fiber Core Diameter: 200μm
Fiber Length: 1m (Customizeable)
Fiber Interface Type: FC/SMA905/LC/SC (Choose)
Fiber Material: Quartz
Coupling Lens Material: Optical glass
Operating Voltage: DC 1.6V
Operating Voltage With Power Diver: DC 12V
Operating Current: <1300mA
Circuit Control Mode: ACC / TTL frequency modulation (Choose)
perating Temperature: -10~50℃
Storage Temperature: -40~85℃
Size: Φ20*70mm
